Descripción

Model hp-SP12INV Seer 18 High Eficiency Rated volt and frequency Ph-v-Hz 220V/60Hz Cooling Cooling capacity w 3500 1800-3900 Cooling power input w 1170? 490-1370 Cooling current input a 5. 3? 2. 8-6. 3 Eer w/w 20 he Max. Input consumption w 1800 Max. Current a 8. 2 Compressor Model ASK103D53UFZ Type (Rotary Piston scroll? Rotary Brand gmcc Indoor Indoor Air Circulation m3/h 600 Indoor Noise Level dB dB(a) 29~41 Dimension (l×w×h) mm 780×270×207 Packing (l×w×h) mm 860×366×305 Net/Gross weight Kg 10/12 Outdoor Outdoor Noise Level dB dB(a) 53 Dimension (l×w×h) mm 715×235×540 Packing (l×w×h) mm 851×335×600 Net/Gross weight Kg 25/32 Refrigerant type/weight g R410A/940 Design pressure (Hi/Low) MPa 4. 2/1. 2 «Refrigerant piping /Connection wiring » Liquid side/ Gas side/Length mm 6. 0+9. 52×7500 «Max. Refrigerant pipe length /Max. Difference in level » m 15/5
